ELECTRIC MOTOR XF57510
51.19 €* price without VAT
| Voltage |
230V – 24V ac 50-60HZ |
|---|---|
| Consumer Power |
5W |
| Running time/90° |
60sec/120sec |
| Torque |
10 N/m Maximum |
| Control signal |
2 point, 3 point or 3 point + AUX |
| Housing material |
Nylon-BASF |
| Position indicate |
Yes, scale on top of housing push |
| Manual control |
to manual, release for auto |
| Cable length |
1 Meter, diameter 6.5mm |
| IP Class |
IP44 |
| Noise level |
Less than40DB |
| Cycles to failure |
100000+ cycles under 5Nm torque |
The 800N electric drive is designed to operate 3/4 way rotary mixing valves, which require a maximum torque of 8 Nm. The electric drive available with 3 point control on-off (2 point control on request) with a supply voltage of 230 V AC (24V AC on request) with 90 angle rotation. The actuator is easily mounted on valves of various European manufacturers, such as Barberi, IVAR, LK, Danfoss, Paw, Meibes, omix and ESBE VRG serial too by G-adapator. The actuator can be manually controlled by the knob, for this you just need to push the handle to unlock and turn the knob, release is to Automatic mode, the shape of knob is very friendly to Finger. The 800N electric drive is compact size, which allows you to mount it anywhere.
